High Frequency Prototype Fr4 PCB Assembly Printed Circuit Board Manufacturers
Electronic Circuit Manufacturing Standard Prototype Fr-4 Pcb Assembly And Pcba
FASTPCBA is Turnkey PCB manufacturer who has over 20 years experience, we Good at HDI(anylayer), Multilayer(4-60L) , High frequency High speed, 5G related PCB, Rigid-Flex, Flex PCB, Components Sourcing, Assembly and Function testing. The superior service we offer our customers high quality, technically advanced products within the customer’s timescales. This commitment, combined with the wealth of experience and expertise we have built up over the years, means we can offer a total solution to our customers from High end PCB to Assembly, Testing in time deliveries.
FASTPCBA provides superior service for automotive electronics, medical electronics, telecommunications, industrial control, smart home and other industries around the world.
FASTPCBA detailed PCB / PCBA capabilities are listed in the table below:
| Article | Description | Capability |
| Laminate Materials | FR4, high TG FR4, high frequency, alum, FPC |
| Board Cutting | Number of layers | 1-48 |
Min.thickness for inner layers
(Cu thickness are excluded) | 0.003”(0.07mm) |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” |
| 4layer:0.01±0.008” |
| 8layer:0.01±0.008” |
| Bow and twist | no more than 7/1000 |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) |
| PTH hole tolerance | ±0.002″(0.005mm) |
| NPTH hole tolerance | ±0.002″(0.005mm) |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) |
| Thickness | (0.012*0.017mm) |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) |
| Component Sourcing | Yes |
| Tolerance of PCB | ±5% |
| Max Size of Finish Board | 700*460mm |
| MOQ | NO MOQ (1pcs) |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… |
| PCB Outline | Square,circle,irregular(with jigs) |
| Package | QFN,BGA,SSOP,PLCC,LGA |
| Sub-assembly | Plastic,metal,screen |
| Min Line/Space | 0.075/0.075mm |
It is easy to get a quote for our PCB prototype assembly; just send the PCB file and bill of materials (BOM) list to pcba24@pcb-smt.net. You will get full price in 24 hours (If you need quick quote, please send your email as “high priority”). Additionally, please include the following:
* BOM list
completeinformation will get a more accurate price—Check BOM sample here
* Gerber files
Quantity required (To save your total cost and delivery time, we accept full BOM purchases, and partial delivery)
Special technology process requirements,if any (like Selective soldering or non-mounted)
Moreover, we have many excellent cooperative factories,they have many QC auditors with rich experience who use advanced testing equipment such as AOI, BGAX-ray and PCB E-test to ensure all our products comply with ISO, UL certifications.
We purchase superior raw materials and components from the authorized dealer, and we have established a quality control department to strictly monitor each production detail. Additionally, all products can be functionally tested upon our customer's requirements to ensure that only qualified products leave our factory.
We are honored as the excellent supplier of many companies all around this world. Our business network extends far to Asia, Europe, America and Australia. Our Magic is Reliable Quality, Competitive Prices, On time delivery, and Excellent Service!
