Multilayer PCB 94v0 fr4 Circuit Board Supplier
FASTPCBA--The leading Prototype PCB, Rigid PCB (1~48Layer), Flexible PCB, Rigid-flex PCB, HDI PCB, Gold-Plated PCB, High Frequency PCB, Small-volume PCB, Superior Difficulty PCB, High Precision PCB in China And we have good service: Faster and delivery on time, and Quick response, reply within 3 hours , We offer 24×7 hours quotation service and engineering support!
Features:
High wiring density, light weight, thin thickness, bending is good!
Best raw materials
High TG, FR4, high frequency (Rogers,Teflon, ARLON, TYCONIC), Halogen-free.
Advanced technology
* min/T/G: 3/3 mil
* Impedance control ±10%
* MAX aspect ratio for board thickness vs drill bit size 15:1
* Surface treatment: HASL, Gold plating, Immersuin gold, Immersuin tin, Immersion silver, Gold fingers, OSP.
FASTPCBA PCB offers a wide range of different printed circuit boards to our customers in the world. We supply you the best quality, best price and heart to heart service.
| Surface treatment | HASL, Gold plating, Immersion gold,Immersion tin, Immersion silver, Gold fingers (Hard gold), OSP |
| Count of layers | double-side to above 40 layers |
| Min track width | 3mil (0.076mm) |
| Min track space | 3mil (0.076mm) |
| Min space between track to pad, pad to pad | 3mil (0.076mm) |
| Minimum drill hole diameter | 6mil (0.15mm) mechanical drill; 4mil (laser drill); |
| Min pads for vias | 12mil (0.3mm) |
| Max aspect ratio | 0.052083333 |
| Max PCB dimension | 700mm*460mm |
| PCB thickness | 8.27-275.8mil (0.21-7.0mm) |
| Max copper weight | 10OZ |
| Soldermask bridge between solder dam | 4mil (0.10mm) |
| Minimum soldermask annular | 1.5mil (0.038mm) |
| Soldermask colors | green, yellow, black, blue, matte, semi-matte, transparent LPI solder mask and peelable soldermask |
| Plugged hole size | 0.15mm- 0.5mm |
| Special material: | HTG FR4, high frequency (Rogers, Teflon, ARLON, TYCONIC), halogen free, different material mixing laminating |
| Special techniques | blind and buried vias (min hole size is 0.1 mm), high layer with heavy copper |
| Remark | the copper foil is 1OZ and 0.5OZ, If the copper foil is above 2OZ (including 2OZ), the above parameter will be changed. |
FASTPCBA has been selected as the “excellent partner of the year” by numerous well-known enterprises, and won many domestic and authorized certifications at home and abroad, such as Chinese high-tech project certification, ISO9001, ISO14001, ISO13485, IATF16949 quality management system standard and customized CE, UL, FCC and other product certifications according to the customer's requirements.
Millions of circuit boards are produced here every year, which provides superior service for automotive electronics, medical electronics, power communications, industrial automation, intelligent home and other industries around the world. We will continue to improve our quality and service; customer satisfaction and development of science and technology are our eternal motivation.
If you have any PCB projects, welcome to contact us. We supply you the best quality, best price and heart to heart service.
Product Tags:
|
|
OEM Multilayer 94v0 Fr4 Circuit Board PCB 48 Layer 10OZ Images
|
