ISO 13485 Certification Medical PCB PCBA Manufacturer
The medical field requires a vast level of technology with extreme reliability and long term life cycles. The medical sector consists of hospitals, doctor’s offices, dental facilities, special care facilities, ambulance services, and fire and rescue. FASTPCBA is proud to be a medical printed circuit board manufacturer and we take pride in ensuring your medical equipment works flawlessly.
There are so many applications of printed circuit boards in the medical field, and the list is continually growing. Printed circuit boards provide the power for pacemakers, defibrillators, heart monitors, and even medical imaging systems. When lives are on the line, there is no room to have a medical machine breakdown, which is why FASTPCBA is fully committed to producing the most reliable and long-lasting printed circuit boards in the medical industry.
High speed laminates, copper and aluminum substrates, ceramics, and extensive coating options give the medical device manufacturer maximum latitude. Precise lot control is a strength within the FASTPCBA manufacturing operation. High levels of cleanliness are paramount in the industry and are a key focus at FASTPCBA.
Multiple PCB Assembly Services :
* Prototype PCB Assembly
* Low-Volume, High Mix PCB Assembly
* High-Volume PCB Assembly
* Consigned & Partial PCB Assembly
* Full Turnkey PCB Assembly
* Cable and Wire Harness Assembly
* Box Build Assembly Services
PCB Manufacturing and PCB assembly capabilities:
| Article | Description | Capability |
| Laminate Materials | FR4, high TG FR4, high frequency, alum, FPC |
| Board Cutting | Number of layers | 1-48 |
Min.thickness for inner layers
(Cu thickness are excluded) | 0.003”(0.07mm) |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” |
| 4layer:0.01±0.008” |
| 8layer:0.01±0.008” |
| Bow and twist | no more than 7/1000 |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) |
| PTH hole tolerance | ±0.002″(0.005mm) |
| NPTH hole tolerance | ±0.002″(0.005mm) |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) |
| Thickness | (0.012*0.017mm) |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) |
| Component Sourcing | Yes |
| Tolerance of PCB | ±5% |
| Max Size of Finish Board | 700*460mm |
| MOQ | NO MOQ (1pcs) |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… |
| PCB Outline | Square,circle,irregular(with jigs) |
| Package | QFN,BGA,SSOP,PLCC,LGA |
| Sub-assembly | Plastic,metal,screen |
| Min Line/Space | 0.075/0.075mm |
Certification:
Through IS013485: 2016 certification, it not only proves that under the quality assurance system, FASTPCBA can continuously provide high-quality products that meet the needs of medical device customers, and further demonstrates our company's higher requirements for product quality standards. The successful passing of this IS013485: 2016 certification is an endorsement of FASTPCBA product quality and safety regulations aspects.
Advanced PCBA Equipment
We have imported the advanced machinery from US,Japan,German and Israel to improve our production and technical ability.We have set a great example the PCB field of flying probe testing,buried and blind via and special controlled impedance.We have a highly developed R&D division which has helped our factory successfully produce mechanical micro via,high density impedance and HDI.
THE FOLLOWING REPRESENTS A FEW MEDICAL APPLICATIONS UTILIZING PRINTED CIRCUIT BOARDS:
Ventilators
Sterilization Equipment
Hospital Communication Equipment
Medical Testing Equipment
Emergency Vehicle Equipment
Blood glucose monitors
X-ray computed tomography
Heart monitors
Blood pressure monitors
Heart pacemakers
Body temperature devices
CT scan systems
Ultrasound equipment
Ultrasonic technology
Neurological stimulus
EMG activity systems
Vesicle pressure measurement
Infusion fluid controls
Peristaltic infusion technology
Flow rate and dispensing systems
