One-stop Turnkey PCB Prototype Assembly Service OEM PCB Manufacturer
PCB Fabrication and PCB Assembly is our core services FASTPCBA. From multi-layered to flexible printed circuit boards, FASTPCBA is your one-stop shop. We provide our customers with PCB solutions and services worldwide. especially more than 80% printed circuit board are exported to oversea market. We have full of confidence to meet your quality level.
As a 20 years PCB manufacturer in China, FASTPCBA is providing the latest printed circuit board technologies and highest quality standards for electronics industry. You can trust us to meet your demands, from small volume to mass production whatever the simplest PCB boards or the most complex.
Check out this list of some of the high-quality PCB Fabrication and PCB Assembly services we offer:
<< Printed Circuit Board PCB Fabrication:
Accept Stardard: IPC III, Military, Automotive, Medcial, We offer you expanded PCB capabilities:
* Rigid PCB
* Flexible
* Rigid-flex
* HDI board
* Gold-Plated PCB
* High Frequency PCBs
Specification of PCB Manufacturing:
| Product Name | Printed Circuit Board PCB Fabrication |
| Materials | FR-4/HTG150-180 FR-4/CEM-1/CEM-3/Aluminum/F4B-2 |
| Number of Layer | 1-48 layers (include Rigid-Flex PCB) |
| Board Thickness | Rigid 0.15mm-3.00mm |
| Board Thickness Tolerance | 5-10% |
| Profile Processing | CNC Milling/V-Cut/Mold Flushes |
| Copper Weight Tolerance | ±0.15 oz |
| Copper Thickness | 0.5oz-5oz |
| Min Line Width | 0.1mm |
| Min Space Width | 0.127mm |
| Min Drill Hole Diameter | 0.1mm |
| Max Processing Sheer | 700mm*460mm |
| Silk Screen Min Line Width | 0.15mm |
| Anti-welds resin | Thermosetting resin/Without the gloss resin/Photosensitive resin |
| Soldermask | green,red,blue,white,black,yellow,etc. |
| Flame resistance | 94v0 |
| Certification | ISO 9001:2000,ISO 14001,ISO/TS16949:2002,UL E203640 |
| Approval Standard | IPC-600F |
| Suface Finish | HASL/Nickle/Lead Free HASL/OSP/Gold Plating/Immersion Gold/ENIG/Rosin etc |
<< PCB Assembly
FASTPCBA is China PCB assembly manufacturer ,who offers complete PCB assembly services in Shenzhen, FASTPCBA’s capable of providing turn-key and partial turn-key printed circuit board assembly services.
For full turn-key, we take care of the entire process, including manufacturing of Printed Circuit Boards, procurement of components (100% original) , PCBA Testing , continuous monitoring of quality and final assembly.
Offering:
* PCB Fabrication
* Parts Sourcing
* IC Programming
* PCB Assembly Services
* Cable & Wire Harness Assembly Services
* Box Build Assembly Services
* PCBA Testing
Whereas for partial turn-key, the customer can provide the PCBs and certain components, and the remaining parts will be handled by us.
Detailed Terms for Pcb Assembly:
| Type of Assembly | THD (Thru-Hole Device), SMT (Surface-Mount Technology), Double-sided SMT & THD mixed |
| Solder Type | Water Soluble Solder Paste,Leaded and Lead-Free. |
| Components | Passives parts, smallest size 0201;
BGA, uBGA, QFN, POP, and Leadless chips;
Fine Pitch to 0.8Mils;
BGA Repair and Reball; Part Removal and Replacement
Connectors and terminals. |
| File Formats | Bill of Materials Gerber Files Pick-N-Place File(XYRS). |
| Type of Service | Turn-Key, Partial Turn-Key or Consignment. |
| Component Packaging | Reels,cut tape,Tube and tray,Loose parts and bulk. |
| Testing | X-ray Inspection
AOI (Automated Optical Inspection)
ICT (In-Circuit Test)/Functional Testing |
<< Components Sourcing:
We have years of experience and stable relationships with authorized electronic components manufacturers and distributors, we can make purchase in full accordance with the customer's designated supplier. Can also help customers reviwe and improve the supply chain, identify the specifications of electronic components, lower the cost and avoid the introduction of any defective products. All parts go through 100 percent quality inspection before use, so you always get real, quality parts.
<< Comprehensive Quality Assurance:
We have imported the advanced machinery from US,Japan,German and Israel to improve our production and technical ability.We have set a great example the PCB field of flying probe testing,buried and blind via and special controlled impedance. Finished PCB Assemblies are checked for proper component placement and functionality with a variety of methods including AOI Inspection, In-Circuit testing, and X-Ray inspection. We have a highly developed R&D division which has helped our factory successfully produce mechanical micro via,high density impedance and HDI.
<< Nine Quality Testing Processes:
<< Our PCBA Application:
FASTPCBA has obtained ISO14000 & ISO9001 & ISO13485 & IATF16949 certificates, customers from medical pcba, automotive pcba, industrial pcba, smart home pcba, military pcba, aerospace pcba can work with us worriless.
<< FAQ:
1, What service do you have?
We provide turnkey solution including PCB fabrication, SMT, plastic injection & metal,final assembly, testing and other value-added service.
2, What is needed for PCB & PCBA quotation?
For PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).
For PCBA: PCB information, BOM,Testing documents.
3, How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.
4, What are the main products of your PCB/PCBA services?
Automotive, Medical, Industry Control, IOT, Smart Home, Military, Aerospace.
5, What is your minimum order quantity (MOQ)?
Our MOQ is 1 PCS, sample and mass production all can support.
6, Are you factory?
Our factory is located in 1st Building, No. 18-1, Yuquan East Road, Yulv Village, Gongming Street, Guangming New District shenzhen, china.
