SMT Processing
Now we have SMT Lines and DIP Lines to perform PCB assembly. The precision of chip replacement is up to +0.1MM, this indicates we have professional skills in producing all kinds of printed integrated circuit boards such as SO, SOP, SOJ, TSOP, TSSOP, QFP, BGA and U-BGA with surface-mount technology (SMT), thru-hole technology (THT) and merged tech components.
DIP Processing
SATECH has three DIP processing lines, professional working platforms and carriers, this ensures a output capacity of 1 500 000pcs per day. For every process, technical and standard operation guidelines are made to follow, with strict KPI, this makes sure of 99.8% of pass for every PCBA. Lower our rejects, create more value for clients.
PCB Fabrication Center
We have produced all kinds of PCBs including FR4, FR1, CEM1, FPC, Metal Core PCB and Rogers PCB, etc. With the advantage of material and component sourcing channels, we have the ability of fast PCB sample--48 hours after order confirmation.
PCB Capability
| Article | Description | Capability |
| Material | Laminate materials | FR4, High TG FR4, High Frequency, Alum, FPC... |
| Board Cutting | Number of layers | 1-48 |
Min.thickness for inner layers
(Cu thickness are excluded) | 0.003”(0.07mm) |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” |
| 4layer:0.01±0.008” |
| 8layer:0.01±0.008” |
| Bow and twist | no more than 7/1000 |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) |
| PTH hole tolerance | ±0.002″(0.005mm) |
| NPTH hole tolerance | ±0.002″(0.005mm) |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) |
| Thickness | (0.012*0.017mm) |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) |
| Max Size of Finish Board | 700*460mm |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… |
| PCB Outline | Square,circle,irregular(with jigs) |
| Package | QFN,BGA,SSOP,PLCC,LGA |
Delivery Time for PCBA
| Order Conditions | Standard Delivery Date | The fastest Delivery Date |
| Prototype (<20 pcs) | 2 days | 8 hours |
| Small Volum (20-100 pcs) | 3 days | 12 hours |
| Medium Volum(100-1000 pcs) | 6 days | 24 hours |
| Mass productions (>1000 pcs) | Depends on BOM | Depends on BOM |
FASTPCBA has been selected as the “excellent partner of the year” by numerous well-known enterprises, and won many domestic and authorized certifications at home and abroad, such as Chinese high-tech project certification, ISO9001, ISO13485, IATF16949 quality management system standard and customized CE, UL, FCC and other product certifications according to the customer's requirements.
Millions of circuit boards are produced here every year, which provides superior service for automotive electronics, medical electronics, power communications, industrial automation, intelligent home and other industries around the world. We will continue to improve our quality and service; customer satisfaction and development of science and technology are our eternal motivation.
With 20 years pcb fabrication and pcb assembly experienced, FASTPCBA has occupied a place in medical pcb assembly,automotive circuit board, smart home pcb fabrication, communication pcba, industry pcb production, military & aerospace pcba etc.
