Medical Advanced Aerospace Automotive Custom Pcb Assembly Circuit Board Assembly

  • 1
  • 2
  • 3

Brand Name : FASTPCBA

Model Number : PCB Assembly

Certification : IATF16949, ISO13485, ISO9001

Place of Origin : China

MOQ : 1pcs

Price : 1-20

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 150000 Pieces per Month

Delivery Time : 5

Packaging Details : PCB: Vacuum Packing/ PCBA: ESD Packing

Pcb assembly : one-stop electronic manufacxturer service

Laminate materials : FR4, High TG FR4, High Frequency, Alum, FPC

Number of layers : 1-48

Function Test : 100% Functional test

Min line/space : 0.075/0.075mm

service business include : aerospace, automotive, medical

Contact Now

Aerospace Automotive High TG FR4 Pcb Fabrication Service



Product Parameter:



Laminate materials

FR4, High TG FR4, High Frequency, Alum, FPC...

Number of layers

1-48

Min.thickness for inner layers
(Cu thickness are excluded)

0.003”(0.07mm)

Standard

(0.1-4mm±10%)

Board Thickness

Single/Double:0.008±0.004”

4layer:0.01±0.008”

8layer:0.01±0.008”

Bow and twist

no more than 7/1000

Outer Cu weight

0.5-4 0z

Inner Cu weight

0.5-3 0z

Min size

0.0078”(0.2mm)

Drill deviation

±0.002″(0.05mm)

PTH hole tolerance

±0.002″(0.005mm)

NPTH hole tolerance

±0.002″(0.005mm)

Color

Green,white,black,red,blue…

Min solder mask clearanace

0.003″(0.07mm)

Solder Mask Thickness

(0.012*0.017mm)

Silkscreen Color

white,black,yellow,blue…

Silkscreen Min size

0.006″(0.15mm)

Max Size of Finish Board

700*460mm

Surface Finish

HASL,ENIG,immersion silver,immersion tin,OSP…

PCB Outline

Square,circle,irregular(with jigs)

Package

QFN,BGA,SSOP,PLCC,LGA



Medical Advanced Aerospace Automotive Custom Pcb Assembly Circuit Board Assembly



Application Fields



We produce PCBs for our customers working in frequency ranges from LED products to communication equipments and in industries as diverse as Medical devices through to automotive, aerospace and Bluetooth etc.



Medical Advanced Aerospace Automotive Custom Pcb Assembly Circuit Board Assembly

Medical Advanced Aerospace Automotive Custom Pcb Assembly Circuit Board Assembly

Medical Advanced Aerospace Automotive Custom Pcb Assembly Circuit Board Assembly



FASTPCBA Technology Co., Ltd is a professional PCB manufacturer in China, Shenzhen. With 20 years of development, FASPCBA turns into a first class manufacturer of HDI PCB, with production capability 35,000 square meters. FASTPCBA is providing high quality bare PCB and PCB assembly service,including components sourcing, function test,conformal coating and complete assembly for clients all over the world, Our main market is Europe, north USA, Australia, South America, and Asia.





FASTPCBA has been selected as the “excellent partner of the year” by numerous well-known enterprises, and won many domestic and authorized certifications at home and abroad, such as Chinese high-tech project certification, ISO 9001, IATF 16949 quality management system standard and customized CE, UL, FCC and other product certifications according to the customer's requirements.



Medical Advanced Aerospace Automotive Custom Pcb Assembly Circuit Board Assembly
