Proto OEM SMD DIP PCBA PCB Assembly Testing Smt Electronics Manufacturing
FASTPCBA has been at the forefront of the PCB and PCBA industry. With over 20-year continuous innovation and improvement based on customers' need, we have been growing fast, and becoming a leading global PCB manufacturer, who provides the rapid production of high-reliability and cost-effective PCB & PCBA and creates the best customer experience in the industry.
With complete dust free & esd protection smt workshop, FASTPCBA has win trust and support from domestic and abroad customers of industrial control, medical,power communication, automotive etc. All pcba products here abide by ISO9001 & ISO13485 & ISO14000 &IATF16949 certificates, reliable and stable pcb manufacturing and assembly service are assured.
Product Description:
| Article | Description | Capability |
| Sercive | PCB and SMT assembly with one-stop service |
| Material | Laminate materials | FR4, high TG FR4, high frequency, alum, FPC |
| Board cutting | Number of layers | 1-48 |
| Min.thickness for inner layers (Cu thickness are excluded) | 0.003”(0.07mm) |
| Board thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” |
| 4layer:0.01±0.008” |
| 8layer:0.01±0.008” |
| Bow and twist | 7/1000 |
| Copper weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) |
| PTH hole tolerance | ±0.002″(0.005mm) |
| NPTH hole tolerance | ±0.002″(0.005mm) |
| Solder mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) |
| Thickness | (0.012*0.017mm) |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) |
| E-test | Function Test | 100% Functional test |
| PCBA Testing | X-ray,AOI Test,Functional test |
| Pcb assembly | one-stop service electronic manufacxturer service |
| Component sourcing | Yes |
| Certificate | IATF16949, ISO13485, ISO9001, ISO14001 |
| Delivery time: | PCB | 3-12days |
| PCBA | 8-20days |
| Tolerance of pcb | ±5% |
| Max size of finish board | 450*450mm |
| MOQ | NO MOQ (1pcs) |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… |
| PCB outline | Square,circle,irregular(with jigs) |
| package | QFN,BGA,SSOP,PLCC,LGA |
| Sub-assembly | Plastic,metal,screen |
We can provide one-stop Pcb Assembly Service:
1. High-end, Small volume and Various kinds of PCBA service offered;
2. Speedy, Flexible and one-stop service in PCBA;
3 Assembly and Purchasing service offered, all components are promisedpurchased 100% from Original factories or their pointed agents;
4. Transparent quotation,cost and benefit are detailedly opened to customer;
5. With professional Engineers and Long-term successful experience in cooperating with customers inland and overseas,all new projects can be developed faster and better than expected;
6. With USA or Japan imported tin cream and tin bar, and 100% AOI testing during production, all PCBAs we made are more reliable.
Quality Control
1. AOI Testing
Checks for solder paste
Checks for components down to 0201"
Checks for missing components, offset, incorrect parts, polarity
2. X-Ray Inspection
X-Ray provides high-resolution inspection of:
BGAs
Micro BGAs
Chip scale packages
Bare boards
3. In-Circuit Testing
In-Circuit Testing is commonly used in conjunction with AOI minimizing functional
defects caused by component problems.
4. Power-up Test
Advanced Function Test
Flash Device Programming
Functional testing
PCB Assembly Application:
FASTPCBA is a turnkey pcb manufacturing and assembly factory indeed, with our own pcb factory separated from pcba company. PCBA service cover communication, medical, automotive, industry, smart home, aviation, military etc.
Product Tags:
|
|
Proto OEM SMD DIP PCBA PCB Assembly Testing Smt Electronics Manufacturing Images
|
